Signal Sources

small logo

Categories:

sigsrc
General Purpose - Function & Pulse Generator
MODEL RANGE INTRO Pg HP-JRNAL COMMENTS
200B AUDIO 1941 7 1951 12 Audio Oscillator 20Hz to 20kHz in 3 Ranges ("Electronics" Pub 1939 )
200BR AUDIO 1941 5 1951 12 Audio Oscillator 20Hz to 20kHz in 3 Ranges - 22,5 V into 500 Ohms
200C AUDIO 1941 5 1951 12 Audio Oscillator 20Hz to 200kHz ("Electronics" Pub 1946 )
200CD AUDIO 1952 8 1952 12 Audio Oscillator 5Hz to 600kHz
200CDR AUDIO 1952 8 1952 12 Audio Oscillator 5Hz to 600kHz - Rack Version of the HP 200CD
200D AUDIO 1941 5 1951 12 Audio Oscillator 7Hz to 70kHz in 4 Ranges - 100mW Output into 1000 Ohms
200I AUDIO 1945 4 1951 12 Audio Oscillator 5Hz to 6300Hz ("Electronics" Pub 1946 ))
200T AUDIO 1955 2 1957 05 Audio Oscillator 250Hz to 100KHz in 5 Ranges - High Stability for Telemetering Applications
201B AUDIO 1945 8 1949 12 Low Distortion Audio Oscillator 20Hz to 20kHz - 3W into 600 Ohms - Less than ,5% Dist.
201C AUDIO 1956 6 1956 02 Audio Oscillator 20Hz to 20kHz - 3 Watts into 600 Ohms - 40 dB Atten 10 dB Steps
202A VLF 1952 10 1951 06 Function Generator ,008 to 1200Hz in 5 Ranges - Sin, Sqr, Triangle 30VPP into 4KOhms
202B VLF 1948 10 1951 12 Low Frequency Oscillator - 0,5Hz to 1000Hz in 4 Ranges - 10V into 1000 Ohms Output
202D AUDIO 1941 12 1951 12 Audio Oscillator 2Hz to 70kHz in 5 Ranges - 100mW Output into 1000 Ohms
203A VLF 1965 258 1965 07 Variable Phase Function Generator - 5mHz to 60kHz - Sin & Sq x 2 Channels Output
204A AUDIO 1950 13 1951 12 Portable Audio Oscillator 2Hz to 20kHz in 4 Decade Ranges - 5V Max Output - Battery Operated
204B RF 1961 43 - Portable Oscillator 5Hz to 500kHz - 2,5 mW into 600 Ohms Floating - 40 dB Level Control
204C RF 1969 375 1968 12 Sinewave Generator - 5Hz to 1,2MHz in 6 Bands - 2,5Vrms into 600 Ohms
205AG AUDIO 1941 13 1952 08 High Level Audio Oscillator - 20Hz to 20kHz - 5 Watts Out - 50-200-600-5KOhms
206A AUDIO 1948 14 1952 08 Audio Signal Generator - 20Hz to 20kHz - +15dBm into 50-150 and 600 Ohms
208A RF 1964 17 - Test Oscillator 5Hz to 560kHz - 2,5V Output into 600 Ohms - Same as 204B with Output Level Meter
210A PULSE 1941 23 - Square Wave Generator 20Hz to 10kHz - 60V PP Open Circuit - 70 dB Ouput Attenuator
211A PULSE 1955 24 1955 05 Pulse Generator 1 Hz to 1MHz - 20ns Rise Time - 27V into 600 Ohms
211B PULSE 1967 311 - Square Wave Generator 1Hz to 10MHz - ,05 to 5V into 50 Ohms
212A PULSE 1950 28 1950 02 Pulse Generator 50 to 5,000 pps Repetition Rate - 20ns Rise Time - 50V into 50 Ohms
214A PULSE 1963 59 1963 10 Pulse Generator 200Watts 10Hz to 1MHz - 13ns Rise Time - 100V into 50Ohms
215A PULSE 1962 5 1962 10 Pulse Generator 1ns Rise Time - 100Hz to 1MHz Repetion Rate - 10V into 50 Ohms
222A PULSE 1966 29 - Pulse Generator - 10MHz Repetition Rate - 10V into 50 Ohms
239A AUDIO 1979 347 - Low Distortion Oscillator 10Hz to 110kHz -95dB THD (,0018%) 1mV to 3,16V RMS into 600 Ohms
241A AUDIO 1962 4 1963 08 Push-Button Audio Oscillator - 3 digit Resolution - 10Hz to 1MHz
1900A PULSE 1969 356 1969 04 Pulse Generator Mainframe for 1900 Series Plug-in
1905A PULSE 1969 359 1969 04 Rate Generator for 1900A Mainframe - 25Hz to 25 MHz in 6 Ranges - Rise Time <5ns - 1V into 25 Ohms
1908A PULSE 1969 359 1969 04 Delay Generator for 1900A Mainframe - 15ns to 10ms in 6 Ranges - Repet. Rate 0 to 25MHz
1917A PULSE 1970 260 1969 04 Variable Transition Time Output for 1900A Mainframe - 10ns to 40ms in 7 Ranges - Up to 10V into 50 Ohms
3300A RF 1965 256 1965 11 Function Generator ,01Hz to 100kHz in 7 Ranges - Sin, Sqr, Triangle 15 VPP into 600 Ohms
3301A NA 1965 256 1965 11 Auxiliary Plug-In for 3300A Function Generator
3310A RF 1970 273 - Function Generator ,5mHz to 5MHz - Sin, Sq, Triangl, Ramp, Pulse 15mV to 15VPP
3311A RF 1973 325 - Function Generator ,1Hz to 1MHz - Sin, Sq, Triangle 100mV to 10VPP into 600 Ohms
33120A RF 1994 442 - Synthesized Function Gen. 100µHz to 15MHz - Sin, Sq, Triang, Ramp, and Arbitrary - 50mV to 10VPP Out
3312A RF 1975 333 1975 03 Function Generator ,1Hz to 13MHz in 8 Decade - Sin, Sq, Triangl, Ramp, Pulse, AM, FM, Burst
3314A RF 1983 334 - Synthesized Function Gen. 1mHz to 20MHz - Sin, Sq, Triang, Ramp, and Arbitrary - 1mV to 10VPP Out
4204A RF 1967? 325 - Digital Oscillator - 10Hz to 1MHz - 4 digit Resolution - -70 to +22 dBm into 600 Ohms
650A RF 1948 16 1951 12 Test Oscillator 10Hz to 10MHz in 5 Ranges - -50 to +12dBm in 600 Ohms
651B RF 1967 328 1965 06(A) Test Oscillator 10Hz to 10MHz in 6 Ranges - 200mW into 50 Ohms - 90dB Output Atten.
652A RF 1967? 329 - Test Oscillator - 10Hz to 10MHz in 6 Bands - ,1mV to 3V rms into 50 or 600 Ohms
654A RF 1969 382 - Test Oscillator 10Hz to 10MHz - +11 to -90dBm in 50, 75 Ohms Unbal or 135, 150, 600 Bal
61014A RF 1986 196 1986 05 PC Instrument Function Generator - 10Hz to 5MHz Sin & Sqr - 8mV to 10VPP Output
70300A MW 1986 647 - MMS 2 slots Tracking Generator 20Hz to 2,9GHz - 0 to -25 dBm Leveled 50 Ohms Output
8003A PULSE 1968 323 - Pulse Generator 10 MHz Repetition Rate - 5ns Rise Time - 2V into 50 Ohms
8005A PULSE 1969 346 - Pulse Generator ,3Hz to 10MHz Repetition Rate - 10ns to 2s Rise & Fall Time - 5V into 50 Ohms
8008A PULSE 1972 305 - Pulse Generator 200MHz Repetition Rate - 1ns Rise Time - 2 x 4V complement. Output
8012B PULSE 1974? - - Pulse Generator 50MHz Repetition Rate - 5ns Rise Time - 5V into 50 Ohms
8082A PULSE 1975 303 1974 09 Pulse Generator 250MHz Repetition Rate - <1ns Rise Time - 5V into 50 Ohms
8165A RF 1978 340 1978 12 Programbl. Signal Source 1mHz to 50MHz - Sin, Sq, Pulse
8403A MW 1964 24 - Pulse Modulator 50Hz to 50KHz for 8430 Series PIN Diode µWave Modulator
8406A MW 1967 396 1966 09 Comb Generator 1-10-100MHz Harmonics up to 10GHz for SA Freq. Calibration
8443A VHF 1971 78 1970 07 Tracking Generator / Counter 100kHz to 110MHz for 141T/8553B Spectrum Analyser
8444A UHF 1973 386 1971 09 Tracking Generator ,5 to 1300MHz for 8558-8568 or 141T series Spectrum Analyzer
8714A MW 1962 14 1963 03 Pulse Generator for µWaves Pin diode Modulators
siggen
Signal Generators
MODEL RANGE INTRO Pg HP-JRNAL COMMENTS
11715A VHF 1980 545 1979 11 AM/FM Test Source for 8901 Modulation Analyzer
202H VHF 1964 29 - AM-FM Signal Generator - 54 to 216MHz in 2 Bands
230B VHF 1970 471 - Power Amplifier for 608 Siggen - 10 to 500MHz in 6 Bands - 4,5 Watts Output - 30dB Gain
3200B VHF 1966 31 - VHF Oscillator 10 to 500MHz - 25 to 250mW Output - Internal AM
3205A MW 1968 372 - FM Telemetry Signal Generator 2 Bands: 1430 to 1540MHz & 2150 to 2310MHz, -10 to -127dBm Calibrated Output
606A RF 1958 15 1959 05 RF Signal Generator 50kHz to 65MHz in 6 Bands - ,1µV to 3V - Internal AM
606B RF 1967 334 - RF Signal Generator 50kHz to 65MHz in 6 Bands - ,1µV to 3V - Internal AM - External FrequencyLock Input
608A VHF 1950 40 1950 03 VHF Signal Generator 10 to 500MHz in 5 Bands - ,1µV to 1V - Internal AM 400 or 1000Hz
608B VHF 1952 58 - VHF Signal Generator 10 to 400MHz in 5 Bands - ,1µV to ,8V - Internal AM
608C VHF 1955 66 1954 08 VHF Signal Generator 10 to 480MHz in 5 Bands - ,1µV to 1V - Internal AM
608F VHF 1966 31 - VHF Signal Generator 10 to 480MHz in 5 Bands - Same as 608E with External FrequencyLock Input for the HP 8708A Synchronizer
610B UHF 1948? 20 - UHF Signal Generator 500 to 1350MHz in 1 Range - 0,1uV to 0,1V Piston Atten. - Internal Pulse Mod.
612A UHF 1952 60 1953 03 UHF Signal Generator 450 to 1230MHz in 1 Band - ,1µV to ,5V - internal AM
616A MW 1948 18 1952 05 UHF Signal Generator 1,8 to 4GHz - 0 to -127dBm - internal Pulse or FM Modulation
616B MW 1960 108 1952 05(A) UHF Signal Generator 1,8 to 4,2GHz - 0 to -127dBm - internal Pulse or FM Modulation
620A MW 1953 2 1954 01 Microwave Signal Generator 7 to 10,8GHz - 0,1 µV to 71mV - internal Pulse or FM Modulation
624C MW 1955 74 1951 10(A) X-Band Test Set 8,5 to 10GHz 3uV to 223mV into 50 Ohms - Internal Power & Wave Meter
8601A VHF 1969 387 1968 08 Generator/Sweeper 100kHz to 110MHz - AM/FM Modulation + Sweep
8614A MW 1962 14 1963 06 UHF Signal Generator 800 to 2400 MHz - Leveled Output 0 to -127dBm - Int. Square Mod. Ext. AM/FM
8640A UHF 1973 339 1973 02 Signal Generator - Cavity Tuned 450kHz to 550MHz - AM-FM - Mechanical Tunning Dial
8640B UHF 1973 339 1973 02 Signal Generator - Cavity Tuned 450kHz to 550MHz Phase Locked - AM-FM
8640M UHF 1976 337 - Signal Generator - Ruggedized version of the 8640B + Reverse Power Protection
8642A UHF 1985 442 1985 12 Synthesized Signal Generator 100kHz to 1057MHz - 1Hz Res. AM-FM-PM +20dBm Output
8651A RF 1972 272 - RF Oscillator 22kHz to 70MHz in 7 Ranges -40 to +20dBm in 10dB steps + Level vernier
8654A UHF 1972 272 1974 03 Signal Generator - 10 to 520MHz in 6 Bands - -130 to +10dBm - AM - FM
8655A UHF 1976 339 1976 03 Synchronizer-Counter for 8654A-B Signal Generator - 1Hz to 520MHz
8656B UHF 1985 440 - Synthesized Signal Generator 100kHz to 990MHz - 10Hz Resolution -AM-FM
8657A UHF 1989 359 - Synthesized Signal Generator 100kHz to 1040MHz - 10Hz Res. -AM-FM -130 dBc/Hz SSB Phase Noise
8657B MW 1990 360 - Synthesized Signal Generator 100kHz to 2060MHz - 1Hz Res. -AM-FM +13 to -143dBm Output
8662A UHF 1980 372 1981 02 Synthesized Signal Generator 10kHz to 1280MHz - 0,1Hz Res. -144 dBc/Hz SSB Phase Noise @ 10kHz
8665A MW 1992 437 - Synthesized Signal Generator 100kHz to 4200MHz -134 dBc/Hz SSB Phase Noise @ 1GHz - AM-FM-PM
8708A RF 1966 32 - Synchronizer for RF/VHF Signal Sources (606 or 608)
8709A RF 1968 396 - Synchronizer for µWave Sources & Network Analyser (8409-8410)
sweeper
Sweep Oscillators
MODEL RANGE INTRO Pg HP-JRNAL COMMENTS
11869A NA 1981 416 - Adapter for 86200 Sweeper Plug-In usage into 8350X Mainframe
670SM MW 1956 13 1954 09 SHF Swept Frequency Oscillator - 2,6 to 4GHz - 10mW Output - Sweep with AC-97 Motor Assembly
675A RF 1968 350 1968 01 Sweep Signal Generator 10kHz to 32MHz - CW, Start Stop & Delta F Sweeper
8340A MW 1983 394 - Synthesized Sweeper 10MHz to 26,5GHz - 1 to 4Hz Resolution - Signal Source for 8510 Network Analyzer
8350A NA 1981 406 1982 02 Sweeper Mainframe for 835XX Drawers
8350B NA 1984 372 - Sweeper Mainframe for 835XX Drawers
83525A MW 1981 412 1982 02 Sweeper Broadband Plug-In for 835X Mainframe - ,01 to 8,4GHz +13 dBm Output Full HP-IB Programable
8601A VHF 1969 387 1968 08 Generator/Sweeper 100kHz to 110MHz - AM/FM Modulation + Sweep
8620A NA 1971 62 1970 11 Sweeper Mainframe for 862XX Drawers
8620C NA 1976 354 - Sweeper Mainframe for 862XX Drawers
8621B MW 1973 363 1970 11 Sweeper Plug-In 1,7 to 4,3GHz for 8620X Mainframe
86220A UHF 1972 290 - Sweeper Plug-In 10MHz to 1,3GHz +10dBm Internal ALC
86222B MW 1976 358 - Sweeper Plug-In 10MHz to 2,4GHz +15dBm Internal ALC & Xtal Marker
86290B MW 1978 388 1975 03 Sweeper Plug-In 2 to 18,6GHz +10dBm Internal ALC
8690B MW 1969 424 - Sweep Oscillator Mainframe for 869X Drawers - Start-Stop or Center & delta F Sweep
8692A MW 1966 29 - Sweeper Drawer for 8690A/B Mainframe - 2 to 4GHZ - 70mW max Output
synthe
Synthesizers
MODEL RANGE INTRO Pg HP-JRNAL COMMENTS
3320B RF 1973 264 1972 07 Synthesizer ,01Hz to 13MHz -70 to +27dBm
3324A RF 1990 416 - Synthesized Function Gen. 1mHz to 21MHz - Sin, Sq, Triang, Ramp, Multi-Sweep - 40VPP Out (Opt 002)
3325A RF 1979 352 1979 01 Synthesized Function Gen. 1µHz to 21MHz - Sin, Sq, Triang, Ramp
3325B RF 1989 414 - Synthesized Function Gen. 1µHz to 21MHz - Sin, Sq, Triang, Ramp + Discrete Sweep - HPIB & RS232
3326A RF 1985 434 1985 08 2 Channel Synthesizer DC to 13MHz - Sin, Sq, 2Tone, 2Phase
3335A RF 1978 345 - Synthesizer 200Hz to 80 MHz - 1 mHz res.
3336C RF 1980 364 1980 05 Synthesizer 10Hz to 21MHz - ,05db Level accuracy
5103A RF 1965 96 - Frequency Synthesizer , 50Hz to 10MHz in 0,1Hz Increments up to 1MHz, 1Hz Increments up to 10MHz
5105A VHF 1967 544 1967 10 Frequency Synthesizer ,1 to 500MHz in ,1Hz Increments - Requires 5110A Synthesiser Driver
5110A RF 1963 154 1964 05 Synthesizer Driver - Deliver Fixed Frequencies References for 5100A/5105A Synthesizers
5359A PULSE 1978 276 1978 08 Time Synthesizer Programmable Width 5ns to 160ms - Delay 0 to 160ms - Max Repet. Rate 10MHz
8165A RF 1978 340 1978 12 Programbl. Signal Source 1mHz to 50MHz - Sin, Sq, Pulse
86602B UHF 1976 330 1973 03 RF Plug-In 1 to 1300 MHz for 8660 Mainframe
8660A NA 1972 270 1971 12 Synthesiser Mainframe for 866XX Drawer - Thumbwell Switches CW Freq. Adjust
8660C NA 1976 328 1971 12(B) Synthesizer Mainframe for 866XX Drawer - Keyboard Input of Freq.& Digital Sweep
8672A MW 1977 332 1977 11 Synthesized Signal Generator 2 to 18 GHz - 1 to 3 kHz Resolution - Calibrated AM/FM - +3 to -120 dBm
8904A AUDIO 1988 398 1989 02 Multifunction Synthesizer DC to 600kHz Sinewave - DC to 50kHz Sq, Triangle & Ramp
E1440A RF 1990 601 - VXI C-Size Module - Synthesized Function Generator 21MHz - Sine, Square, Triangle, Ramp ( Equivalent to the HP 3325B Synthesized Function Generator)
