MODEL | RANGE | INTRO | Pg | HP-JRNAL | COMMENTS |
---|---|---|---|---|---|
1100A | VHF | 1963 | 51 | - | Delay Line 120ns Delay - 1/4 ns Rise Time - 50 Ohms |
1120A | UHF | 1970 | 534 | 1969 12 | Active Probe 1:1 Div. Ratio, DC to 500MHz, 100Kohms input, 50 Ohms output |
1122A | DC | 1969 | 549 | 1969 12 | Power Supply for up to 4 HP Active Probes ( Oscilloscope or Spectrum Analyzer ) |
1124A | VHF | 1971 | 100 | - | Active Divider Probe 10:1 and 100:1 Div. Ratio, DC to 100MHz, 10Megohms input, 50 Ohms output |
1125A | VHF | 1973 | 174 | - | Impedance Converter Probe for Scopes - 500Hz to 250MHz - 10:1 or 100:1 div - 100KOhms |
1200A | RF | 1969 | 502 | - | Oscilloscope Analog 2x500kHz - 100uV to 20V/div Differencial Input - 1us to 5s/div |
1200B | RF | 1969 | 504 | - | Oscilloscope Analog 2x500kHz - 100uV to 20V/div Differencial Input - 1us to 5s/div |
1222A | RF | 1976 | 144 | - | Oscilloscope Low Cost 2x15MHz - TV Sync - Calibrated XY |
1223A | RF | 1977 | 150 | - | Oscilloscope Analog 2x15MHz- 2mV/div to 10V/div - Variable Persistence CRT / Storage |
122A | RF | 1959 | 12 | 1958 09 | Oscilloscope - 2x200kHz BW - 10mV to 100V/cm |
130A | RF | 1956 | 2 | 1956 03 | Oscilloscope - 300kHz BW - 1mV/cm - 1us to 15sec/cm TB |
130C | RF | 1963 | 30 | 1962 08 | Oscilloscope - 500kHz BW - 200uV to 20V/cm X&Y Ampl - 1us to 5sec/cm TB |
132A | RF | 1965 | 274 | - | Dual-Beam Oscilloscope - 500kHz BW - 1mV to 20V/cm |
1332A | RF | 1975 | 162 | - | X/Y Display - 10x12 cm |
1336A | RF | 1978 | 192 | - | X/Y Display High Resolution - 8x10 cm |
1340A | RF | 1978 | 188 | - | X/Y Display - 10x12 cm |
1345A | RF | 1982 | 241 | 1982 01 | Digital X/Y Display 16bit TTL I/O - 2048x2048 Addressable Resolution (OEM Display in 3577A & 4145A) |
140A | RF | 1963 | 32 | 1963 09 | Oscilloscope Mainframe for 14XX series Drawers |
1400A | RF | 1963 | 32 | 1963 09 | Differencial Amplifier for 140A Mainframe - 400kHz BW - 0,1mV to 20V/cm in 17 Ranges |
1402A | RF | 1964 | 2 | 1963 09 | Dual Trace Amplifier for 140A Mainframe - 20MHz BW - 5mV to 10V/cm in 11 Ranges |
1415A | TDR | 1964 | 2 | - | Time Domain Reflectometer Drawer for 140A Mainframe - 150ps Rise Time - 1 inch Discontinuity Resolution |
1421A | RF | 1964 | 2 | 1963 09 | Time Base & Delay Generator for 140A Mainframe 0,2us to 1s/div in 21 Ranges - Calib. Delay 0,2us to 10s |
150A | RF | 1956 | 4 | 1956 04 | Oscilloscope Mainframe Analog 10MHz for 150 series Drawers - 24 Sweep Ranges from 0,02us to 15sec/cm |
152A | RF | 1956 | 5 | 1956 04 | Dual Channel Amplifier for the 150A - DC to 10MHz - 0,05 to 50V/cm Sensitivity |
1700B | RF | 1973 | 160 | - | Ruggedized Portable Oscilloscope 1700B opt300 - 2x35MHz - ACLine or 12 to 36VDC PS |
1707B | RF | 1973 | 158 | - | Portable Oscilloscope - 2x75MHz - Delayed Sweep - ACLine or 12VDC PS |
1715A | VHF | 1978 | 136 | - | Oscilloscope Analog 2x200MHz |
1722B | UHF | 1978 | 132 | 1974 12 | Oscilloscope Analog 2x275MHz - delta Time |
1727A | UHF | 1981 | 192 | 1982 04 | Oscilloscope Analog 2x275MHz - Storage 2000 cm/us Writing Speed - delta Time & DMM |
1740A | VHF | 1976 | 104 | 1975 12 | Oscilloscope Analog. 2x100MHz |
1743A | VHF | 1978 | 139 | 1977 12 | Oscilloscope Analog 2x100MHz - delta Time |
1744A | VHF | 1979 | 154 | - | Oscilloscope Storage 2x100MHz |
1745A | VHF | 1983 | 186 | - | Oscilloscope Analog. 2x100MHz - Large Screen Version of the 1740A |
1801A | RF | 1967 | 458 | - | 2 Channels Vertical Amplifier for 180 Mainframe - 50MHz BW - 5mV to 20V/div - 7ns Rise Time |
1804A | RF | 1968 | 495 | - | 4 Channels Vertical Amplifier for 180 Mainframe - 50MHz BW - ,02 to 10V/div |
1808A | RF | 1972 | 102 | - | 2 Channels Vertical Amplifier for 180 Mainframe - 75MHz BW - 5mV to 5V/div |
180A | RF | 1966 | 1 | 1966 08 | Oscilloscope Mainframe for 180 Series Drawers - 50MHz BW - |
1815B | MW | 1970 | 528 | - | Sampling Plug-In for 180 Series 12,4Ghz and 35ps Risetime TDR with 1817A sampler |
1817A | MW | 1969 | 542 | - | Sampler for 1815A/B Plug-In - 35ps Risetime TDR with 1106A Tunnel Diode Mount |
1818A | MW | 1972 | 116 | - | General Purpose TDR Plug-In for 180 Series - 120ps Rise Time - 50ps Step Generator - Distance Calibration |
181A | NA | 1968 | 493 | 1968 05 | Analog Storage Oscilloscope Mainframe for 180 series Drawers |
181T | RF | 1975 | 455 | - | Oscilloscope Mainframe for 180 Series Drawers - 100MHz BW - Variable Persistence CRT |
1822A | RF | 1969 | 541 | - | Dual Timebase for 180 Mainframe - 50ns to 1s/div |
182C | NA | 1973 | 124 | - | Oscilloscope Large Screen Mainframe for 180 series Drawers - 100MHz BW |
185B | UHF | 1960 | 2 | 1962 03 | 1000MC Oscilloscope - First 1GHz Sampling Scope - Work with 187B Dual Trace Vertical Amplifier |
186A | UHF | 1962 | 2 | 1962 03 | Switching Time Tester Drawer for 185A-B Mainframe - Measure Rise Time of Diode & Transistor up to 1ns |
187B | UHF | 1961 | 29 | 1962 03 | 2 Chanel Vertical Amplifier for 185A-B Mainframe - 350ps Rise Time - 10 to 200mV/cm |
1980B | VHF | 1982 | 198 | 1982 09 | Oscilloscope Digital 4x100MHz - 2mV/div to 10V/div - Main & Delayed TB 5ns to 1s/div |
4920A | TDR | 1970 | 424 | 1969 06 | Coaxial Fault Analyzer - Cable Fault Locator for CATV - 5Ft/Div to 500Ft/Div |
5180A | RF | 1983 | 171 | 1988 02 | Digital Waveform Recorder 20MHz - 2 Channel - 10 Bits 16K Word |
5183T | RF | 1986 | 422 | 1988 02 | Precision Digitizing Oscilloscope - 2 Channel - 12 Bits Resolution - 4 Mega Samples Sec. |
5185T | RF | 1988 | 64 | 1988 02 | Precision Digitizing Oscilloscope - 2 Channel - 8 Bits Resolution - 250 Mega Samples Sec. |
54120B | MW | 1990 | 60 | - | Digitizing Oscilloscope 4x20GHz Bandwidth 17ps Risetime - 1 to 80mV/div - TDR Measurements |
54121A | MW | 1990 | 60 | - | Sampling Head for 54120B Digitizing Oscilloscope - 4 Channels + Trigger or 3 Channels + TDR |
54503A | UHF | 1990 | 52 | - | Oscilloscope Digital 4x500MHz - Math Function |
54542A | VHF | 1994 | 144 | - | Digitizing Oscilloscope 4x500MHz Repetitive & Single Shot BW - 2GSa/s - 1mV to 5V/div - Math Function |
54600A | VHF | 1992 | 154 | 1992 02 | Digitizing Oscilloscope 2x100MHz - 2mV to 5V/div - Waveform Storage - Save/Recall of 16 Setups |
54710A | MW | 1993 | 130 | - | Digitizing Oscilloscope Mainframe for Up-to 4 Plug-ins - 4-Gsa/s Sampling Rate - 1,5GHz Equiv. Bandwidth |
54712A | MW | 1993 | 131 | - | Plug-in for 54710/720 Oscilloscope - DC to 1,1GHz Bandwidth, 100ps/div to 1s/div, 10mV/div to 1V/div |
61016A | RF | 1986 | 197 | - | PC Instrument Digitizing Oscilloscope - 50MHz Dual Trace - Time Base 100ns to 5s in 1-2-5 sequence |
70700A | RF | 1988 | 110 | - | MMS 1 slot Digitizer 20 Msample/s 10 bit Resolution for 70000 Spectrum Analyzers IF Time Domain Analys |
E1428A | VHF | 1992 | 93 | - | VXI C-Size Module - 2 x 250MHz - 1GSamples/s Digital Oscilloscope - ( Equivalent To the HP 54510A Scope) |
E1431A | RF | 1995 | 89 | - | VXI C-Size Module - 8-Channel 25,6kHz, 16 bit Analog/Digital Input Module |
MODEL | RANGE | INTRO | Pg | HP-JRNAL | COMMENTS |
---|---|---|---|---|---|
141T | NA | 1971 | 80 | 1971 09 | Spectrum Analyzer Variable Persistence Display for 85XX series Drawers |
11729B | MW | 1983 | 514 | - | Low Noise Down Converter for 3047A Signal Analyzer System - 5MHz to 18GHz determined by Options |
11729C | MW | 1986 | 712 | - | Carrier Noise Test Set - AM and Phase Noise Measurmt. 10MHz to 18GHz determined by Options |
11848A | MW | 1987 | 707 | - | Phase Noise Measrmt. Interface for the HP3048A Automated Phase Noise Measrmt. System |
3047A | MW | 1983 | 512 | - | Automated Spectrum Analyzer - HP3585A + HP3582A + HP35601A Interface + 9836 CPU & Software |
3048A | MW | 1987 | 707 | - | Automated Phase Noise Measrmt. System - HP3561A + HP11848A Interface + 9000/S300 CPU & Software |
35601A | MW | 1983 | 512 | - | Spectrum Analyzer Interface for the HP3047A Automated Phase Noise Measrmt. System - 5MHz to 18GHz |
3561A | VLF | 1985 | 627 | 1984 12 | Dynamic Signal Analyzer - Spectrum & Network Analysis 125uH to 100kHz - 80dB Dynamic Range |
3571A | RF | 1976 | 445 | 1975 05 | Tracking Spectrum Analyzer for 3330B Synthesizer 50Hz to 13MHz |
3580A | VLF | 1975 | 452 | 1973 09 | Analog Spectrum Analyzer 5Hz to 50kHz - 1Hz Res. Adapt. Sweep |
3582A | VLF | 1979 | 518 | 1978 09 | 2 Channel Real-Time Spectrum Analyzer ,02Hz to 25,5kHz - FFT |
3585A | RF | 1979 | 488 | 1978 06 | Digital Spectrum Analyzer 20Hz to 40MHz - 3Hz Max Res. |
4195A | UHF | 1988 | 226 | - | Combined Network/Spectrum Analyzer 10Hz to 500MHz - Color Display - Internal Floppy |
70001A | NA | 1986 | 647 | - | Modular Measurement System Mainframe for Up to 8 Plug-in Instrument modules of MMS Series - HP-MSIB |
70004A | NA | 1990 | 117 | - | Color Graphic Display MMS Mainframe for UP to 4 Plug-in Instrument modules of MMS Series - HP-MSIB |
70205A | NA | 1986 | 647 | - | MMS 3 slots Graphics Display & Menu-Driven Control for 70000 Spectrum Analyzers |
70600A | MW | 1988 | 116 | - | MMS 1 slot Preselector for 70000 Spectrum Analyzers - 2,7 to 22GHz Tracking Preselection |
70621A | MW | 1991 | 425 | - | MMS 1 slot Low Noise Preamplifier for 70000 Spectrum Analyzers - 100KHz to 2,9GHz - 24dB Gain |
70900A | MW | 1986 | 647 | - | MMS 2 slots Synthesized Local Oscillator & Controller for 70000 Spectrum Analyzers - 3,0 to 6,6 GHz |
70900B | MW | 1990 | 117 | - | MMS 2 slots Synthesized Local Oscillator & Controller for 70000 Spectrum Analyzers - 3,0 to 6,6 GHz |
70902A | RF | 1986 | 647 | - | MMS 1 slot IF Section for 70000 Spectrum Analyzers - 10Hz to 300kHz Resolution Bandwidth |
70903A | RF | 1986 | 647 | - | MMS 1 slot IF Section for 70000 Spectrum Analyzers - 100kHz to 3MHz Resolution Bandwidth |
70904A | MW | 1986 | 647 | - | MMS 1 slot RF Section for 70000 Spectrum Analyzers - 100Hz to 2,9GHz Front End - 21,4MHz IF Output |
70906A | MW | 1986 | 647 | - | MMS 1 slot RF Section for 70000 Spectrum Analyzers - 50kHz to 26,5GHz Front End - 21,4MHz IF Output |
70908A | MW | 1988 | 116 | - | MMS 1 slot RF Section for 70000 Spectrum Analyzers - 100Hz to 22GHz Preselected Front End |
8441A | MW | 1966 | 10 | 1968 01 | Tracking Preselector for 8551B Spectrum Analyzer - 1,8 to 12,4GHz |
8551A | MW | 1964 | 26 | 1964 08 | Microwave Spectrum Analyzer 10MHz to 10GHz - 1kHz Max Res - BWOscillator |
8552A | NA | 1969 | 326 | 1968 08 | Spectrum Analyzer IF section - 100Hz to 300kHz Resolution |
8552B | NA | 1971 | 80 | 1970 07 | Spectrum Analyser IF section - 10Hz to 300kHz Resolution |
8553B | VHF | 1970 | 405 | 1970 07 | Spectrum Analyser RF section - 1kHz to 110MHz |
8555A | MW | 1971 | 82 | 1971 09 | Spectrum Analyzer RF section - 10MHz to 18GHz |
8558B | MW | 1975 | 135 | - | Spectrum Analyzer Drawer for 180 Series Mainframe 0,1 to 1500MHz - 1kHz to 3MHz BW |
8559A | MW | 1980 | 510 | 1980 03 | Spectrum Analyser Drawer for 180 Series Mainframe 0,01 to 21GHz - 1KHz to 3MHz BW |
8565A | MW | 1978 | 484 | - | Microwave Spectrum Analyzer 10MHz to 22GHz - 1kHz Max Res. |
8568B | UHF | 1985 | 590 | 1978 08 (A) | Automatic Spectrum Analyzer 100Hz to 1500MHz - 10Hz Max Res. |
8590A | UHF | 1986 | 678 | - | Portable Spectrum Analyzer 1MHz to 1500MHz - 1kHz Max Res. |
8901B | UHF | 1984 | 530 | 1979 11 (A) | Modulation Analyzer 150kHz to 1300MHz - Automatic Measurmt. of Freq, Power, AM % & FM Deviation |
MODEL | RANGE | INTRO | Pg | HP-JRNAL | COMMENTS |
---|---|---|---|---|---|
300A | VLF | 1941 | 17 | 1951 08 | Harmonic Wave Analyzer 30Hz to 16kHz - 1mV to 500V FS - Variable Selectivity 3,5 Hz to 14 Hz @ 3dB |
302A | VLF | 1959 | 44 | 1959 09 | Wave Analyzer 20Hz to 50kHz - 1Hz Resolution |
310A | RF | 1963 | 80 | 1963 01 | Selective Level Meter 1kHz to 1,5MHz -AM/USB/LSB Demodulation |
312A | RF | 1967 | 294 | - | Selective Level Meter 1kHz to 18MHz - AM/USB/LSB Demodulation - NIXI Freq. Display |
312B | RF | 1976 | 440 | - | Selective Level Meter 1kHz to 22MHz - AM/USB/LSB Demodulation |
313A | RF | 1967 | 294 | - | Tracking Oscillator for 312A SLM - 10kHz to 22MHz +10 to -99,9dBm into 50Ohms |
3581C | VLF | 1975 | 498 | - | Selective Voltmeter 15Hz to 50kHz - 3 to 300Hz IF BW - 100nV to 30V FS Analog VM |
3586A | RF | 1980 | 592 | 1980 05 | Selective Level Meter 50Hz to 32,5MHz - CCITT Demodulation |
3586C | RF | 1980 | 492 | 1980 05 | Digital Signal Analyzer 50Hz to 32,5MHz - USB/LSB Demodulation |
3590A | VLF | 1969 | 441 | - | Plug-In Wave Analyzer Mainframe for 359X Drawers - 85 dB Dynamic - Unbal. 100KOms Inp. |
3591A | VLF | 1969 | 324 | - | Plug-in Selective Voltmeter Mainframe for 359X Drawers - 3uV to 30V FS - Balanced Input |
3594A | VLF | 1969 | 324 | - | Drawer for 3591A 20Hz to 620kHz - Sweeping LO with XY recorder Output |
417A | VHF | 1950 | 47 | 1950 05 | Super-Regenerative VHF Detector - 10 to 500MHz in 5 Ranges - for 803A Bridge |
MODEL | RANGE | INTRO | Pg | HP-JRNAL | COMMENTS |
---|---|---|---|---|---|
320A | AUDIO | 1941 | 8 | 1951 12 | Distortion Measurement Filter 400Hz to 5kHz - Require External Detector |
330B | AUDIO | 1945 | 16 | 1951 12 | Distortion Meter 20Hz to 20kHz - Sensitivity: Full Scale Deviation for 0,3% Distortion |
330D | AUDIO | 1950 | 31 | 1951 12 | Distortion Meter 20Hz to 20kHz - Meet FCC AM-FM Broadcast Measurements Requirement |
331A | AUDIO | 1965 | 39 | 1966 04 | Distortion Analyzer 5Hz to 600kHz - 0,1% to 100% Dist in 7 ranges |
332A | AUDIO | 1965 | 39 | 1966 04 | Distortion Analyzer 5Hz to 600kHz - 0,1% to 100% Dist in 7 ranges - Same as HP 331A + AM Detector |
339A | AUDIO | 1978 | 469 | - | Distortion Analyser 10Hz to 110KHz - 0,01% to 100% Dist in 9 ranges - THD Measrmt. To 0,0018% |
8903B | AUDIO | 1986 | 722 | 1980 08 | Digital Audio Analyzer 20HZ to 100kHz - Vrms - Distortion - SINAD |
MODEL | RANGE | INTRO | Pg | HP-JRNAL | COMMENTS |
---|---|---|---|---|---|
236A | BB | 1967 | 292 | 1970 12 | Wide-Range Telephone Test Oscillator - 50Hz to 560kHz in 4 ranges, +10 to -31dBm Balanced Output |
3555B | BB | 1969 | 322 | - | Telephone Test meter - Measure Voice, Carrier, and Noise Level - Complete Transmission Test Set when used with 236A Oscillator |
3702B | BB | 1972 | 354 | - | Microwave Link Analyzer - Receiver Mainframe - Combined IF & BB Test Set - 1800 Channels |
3705A | BB | 1972 | 354 | - | Microwave Link Analyzer - Receiver Diff. Phase Detector Plug-in for 3702B Mainframe |
3709A | RF | 1987 | 394 | 1987 07 | Constellation Display for Digital Radio Test - 1 to 80MHz Clock Rate - Radio Eye Diagram & Constellation |
3710A | BB | 1972 | 354 | 1972 09 | Microwave Link Analyzer - IF/BB Transmitter Mainframe |
3716A | BB | 1972 | 354 | - | Microwave Link Analyzer - BB Transmitter Plug-in - 83.3, 250 & 500kHz, 2.4, 4.43, 5.6, & 8.2MHz |
3730A | MW | 1972 | 355 | 1972 09 | Microwave Link Analyzer - Down Converter Mainframe |
3730B | MW | 1981 | 606 | - | Microwave Link Analyzer - Down Converter Mainframe |
3738A | MW | 1973 | 439 | - | Microwave Link Analyzer - Down Converter Plug-in for 3730A Mainframe - 6.3 to 8.5 GHz Input |
3738B | MW | 1981 | 606 | - | Microwave Link Analyzer - Down Converter Plug-in for 3730B Mainframe - 5.9 to 11.7 GHz Input |
3762A | ECL | 1978 | 562 | - | PRBS Data Generator 150Mb/s - Work with 3763A Error Detector |
3779C | BB | 1982 | 584 | - | Primary Multiplex Analyzer - CCITT, CEPT & BELL Compatible - Automatic Meas. Sequencing |
3780A | BB | 1976 | 502 | 1976 03 | Pattern Generator and Error Detector (50 Mb/s) - Patt. Gen Clocks @ 2048, 8448, & 1536kHz |
3789B | BB | 1988 | 478 | - | DS3 Transmission Test Set - DS3 to DS1 Demultiplexer - Full Remote Control HP-IB or RS-232C |
3790A | BB | 1976 | 506 | - | Microwave Link Analyzer - IF/BB Transmitter Mainframe |
3791A | BB | 1976 | 506 | - | Microwave Link Analyzer - BB Transmitter Plug-in - 83.3, 250 & 500kHz, 2.4, 4.43, 5.6, 8.2 & 12.39MHz |
3792A | BB | 1976 | 506 | - | Microwave Link Analyzer - Receiver Mainframe - 140MHz IF Center Freq. - 2700 Channels |
3793A | BB | 1976 | 506 | - | Microwave Link Analyzer - Receiver Diff. Phase Detector Plug-in for 3792A Mainframe |
4948A | BB | 1987 | 374 | - | In-Service Transmission Impairment Measuring Set - 2400 to 9600 bps - North American & CCITT Envrnmt, |
