Logic Analyzers

small logo

Categories:

Logic Analyzers - Probes & Accessories
MODEL RANGE INTRO Pg HP-JRNAL COMMENTS
10230B TTL 1975 82 1975 08 Clock Probe for 1620A or 1601A/L Logic State Analyzers
10231B TTL 1975 82 1975 08 Data Probe for 1620A or 1601A/L Logic State Analyzers
10525A TTL 1970 92 1969 06 Logic Probe
10525T TTL 1973 106 1972 09 Logic Probe for TTL & DTL Logic Circuits Troubleshooting
10526T TTL 1973 107 1972 09 Logic Pulser for TTL & DTL Logic Circuits Troubleshooting
10529A TTL 1973 80 1972 01 Logic Comparator for TTL & DTL Integrated Circuits Troubleshooting
1230A TTL 1976 84 1975 08 Logic Trigger-divider TTL 8 bit
1600A TTL 1976 78 1975 08 Logic Analyzer 20MHz 16bit parallel state - Table or Map Display
1601A TTL 1975 78 1974 01 Logic State Analyzer 12 Bit parallel - 10 MHz Clock - Drawer for 180 Series Oscilloscope Mainframe
1602A TTL 1978 118 1978 02 Logic Analyser General Purpose 10MHz, 16 bit - 64 Word Memory - LED Display Hex, Bin, Dec or Octal
1607A TTL 1976 78 1975 08 Extend 1600A to 32bit or same Specs as 1600A when alone with external Oscilloscope
1610B TTL 1980 137 1980 05 Logic State Analyzer 32 Channel - 10 MHz Clock - 64 Transactions Memory Depth
1611A UPROC 1978 121 1978 02 Logic State Analyzer for Micropross. Based Systems - For 6800, A68, A80, 0F8, Z80
1615A TTL 1979 144 1978 02 Logic Analyzer 24 Channel 20MHz - Simultaneous Time & State infos
1620A TTL 1975 82 1975 08 Pattern Analyzer - 16 Bit Serial/Parallel Digital Triggering for Oscilloscope or Ext. Triggered Instrument
1630A TTL 1984 163 - Logic Analyser 35 Channel 100MHz - State, Timing & Performance Analysis
1630D TTL 1984 163 - Logic Analyser 43 Channel 100MHz - State, Timing & Performance Analysis
1631A TTL 1986 411 - Logic Analyser 43 Channel 100MHz - State, Timing & Perf. Analysis + 2 Channel 50 MHz Digitizing Oscilloscope
1640B TTL 1981 166 - Serial Data Logic Analyzer - RS-232-C V24 - 2048 Char. Memory - For Computer Network Troubleshooting
1645A TTL 1975 497 - Data Error Analyzer - Tr/Rx Up to 6 Channels Simultaneous - 75 to 9600 Bds Bite Rate
1672A TTL 1996 375 - Logic Analyzer 68 Channel 70MHz - 64KSample Memory - Internal Hard-Disk + LAN
3762A ECL 1978 562 - PRBS Data Generator 150Mb/s - Work with 3763A Error Detector
5000A TTL 1975 80 1973 10 Logic Analyzer 2 Channel - Logic State VS System Time Display
5004A TTL 1978 108 1977 05 Signature Analyzer - 4 Digits Hexa. 10MHz Max. Clock Frequency - 10ns Min. Pulse Width
5005A TTL 1982 153 1977 05 Signature Analyzer + DMM - Portable version of 5005B Without HPIB
5005B TTL 1983 127 1977 05 Signature Analyzer + Digital Multimeter DCV/OHMS/FREQ to 50MHz
5011T TTL 1973 104 - Logic Troubleshoot Kit - Logic Probes + Logic Clip + Comparator
5035T NA 1975 88 1974 11 Logic Breadboard for Digital Circuits Experiments - Include 5V 1A Supply & TTL Clock
5036A UPROC 1979 121 1979 10 Microprocessor Lab - Processor technology learning tool & course
545A TTL 1977 103 1976 12 Logic probe TTL/CMOS 40MHz
546A TTL 1977 104 1976 12 Logic pulser TTL/DTL/CMOS
547A TTL 1977 105 1976 12 Digital Current Tracer - Display in-circuit Current Flow from 1mA to 1A
548A TTL 1977 106 1976 12 Logic Clip for 14 or 16 pins DIL packages
8016A TTL 1975 316 1975 08 Word Generator 9x32 bit - 50MHz Rep.Rate - TTL or ECL Output
8018A TTL 1978 326 - PRBS Generator Serial Data 50MHz - 2048 bit 2 Channels TTL, ECL, CMOS
8175A TTL+ 1986 470 - 50 MHz Digital Signal Generator - 24 Channels, 1 Kbit/50Mbit each, Programmable Pattern 20ns to 9,99s
64000 UPROC 1980 132 1980 10 Development System for Microprocessor-based Systems
