Categories:



Power Supplies
MODEL RANGE INTRO Pg HP-JRNAL COMMENTS
1122A DC 1969 549 1969 12 Power Supply for up to 4 HP Active Probes ( for scope or SA )
6002A DC 1977 191 1977 07 Power Supply 200W - 0 to 50V - 0 to 10A - HPIB Programming with opt 001
6112A DC 19661 20 - Precision Laboratory Bench Supply 0 to 40V, 1mV Steps with 5 Digit Thumbwheel Switchs - 500mA Max.
6200B DC 1966 15 - Power Supply - 2 Ranges 0 to 20V @ 1,5A or 0 to 40V @ 0,75A
6203B DC 19661 12 - Harrison Division Lab Bench Supply 0 to 7,5V - 3A Max.
6209B DC 1967 470 - High Voltage Power Supply 0 to 320V @ 100mA
6227B DC 1970 13 - Dual Power Supply 2 x 0 to 25V - 2A Max - Independant or Tracking Operation
6236B DC 1978 204 - Triple Outputs Power Supply 0 to 6V at 2,5A and 0 to +20V and 0 to -20V at 500mA Max.
6263B DC 1969 576 - Low Voltage Rack Supply 0 to 20V - 10A Max.
6268B DC 1970 21 - Low Voltage Rack Supply 0 to 40V - 30A Max.
6299A DC 19661 17 - Harrison Division Lab Bench Supply 0 to 100V - 750mA Max.
6824A ACDC 19661 45 - Harrison Division Lab DC Power Supply and Amplifier -50 to +50V DC at 1A, and 100V PP as Amplifier
6826A ACDC 1973 199 1974 07 Power Supply / Amplifier -50 to +50V @ 1A - Amplifier X1 or X10, 50Vpk @ 1A DC to 40KHz
6920B ACDC 19661 6 - AC-DC Meter Calibrator - DCV 10mV to 1000V - DCA 1ľA to 10A
710A DC 1946 32 - Power Supply Unit 180 to 360V DC 100mA Max + 6,3V AC - (First HP Power Supply)
711A DC 1955 6 - Laboratory Power Supply 0 to 500V DC 100mA Max + 6,3V AC @ 5A - Current & Voltage Front Panel Meters
715A DC 1952 70 1950 12 Klystron Power Supply - 250 to 400V Beam Supply - 0 to 900V Reflector Supply - 6,3V Filament Supply
721A DC 1958 14 1958 05 Transistor Power Supply 0 to 30V 150mA Max. - (First HP Fully Transistorized Product)
E3611A DC 1993 478 - Dual Output Power Supply 0 to 20V at 1,5A Max. or 0 to 35V at 850mA Max. - Digital Readout of V & I
E3631A DC 1996 165 - Triple Output Laboratory Power Supply 0 to 6V at 5A Max. and 0 to +25V & -25V at 1A Max.

* 1 - 1966 Power Supplies Catalog



Many equipments from others HP divisions are avaible in the collection but are not yet classified.
This chapter will be upgraded step by step as work goes on.
