Network Analyzers

small logo

Categories:

Scalar & Vector Network Analyzers
MODEL RANGE INTRO Pg HP-JRNAL COMMENTS
3561A VLF 1985 627 1984 12 Dynamic Signal Analyzer - Spectrum & Network Analysis 125uH to 100kHz - 80dB Dynamic Range
3562A VLF 1985 630 - Dual-Channel Dynamic Signal Analyzer - 64uH to 100kHz - Spect, Netwk & Waveform
35677A VHF 1985 544 1984 11 S Parms Test Set 100kHz to 200MHz - 50 Ohms - For 3577A
3570A RF 1973 408 1972 10 Tracking Network Analyzer for 3330B Synthesizer 50Hz to 13MHz
3575A RF 1973 414 1972 05 Digital Gain/Phase Meter 1Hz to 13MHz - dBv, dBm & Phase display
3577A VHF 1985 544 1984 11 Digital Network Analyzer 5Hz to 200MHz - 100 dB Dynamic
415A MW 1950 45 1950 01 Standing Wave Indicator - Meter Scales in SWR & dB - Work with 8XX Slotted Line
415B MW 1955 103 1955 03 Standing Wave Indicator - Meter Scales in SWR & dB - Work with 8XX Slotted Line
416A MW 1954 6 1954 09 Ratio Meter - Indicate VSWR or Reflection Coeff. - Work with Square Law Crystal Detectors or Barretters
41952A UHF 1989 233 - Transmission/Reflection Test Set for 4195A - 100kHz to 500MHz -50Ohms, 40 dB Direct,
4195A UHF 1988 226 - Combined Network/Spectrum Analyzer 10Hz to 500MHz - "S" Parms, Smith Chart
4800A RF 1965 106 1967 01 Vector Impedance Meter 5Hz to 500kHz - Measure of Z 1Ohm to 1MOhm & Phase +/-90°
4815A VHF 1966 SF 1967 01 RF Vector Impedance Meter ,5 to 108MHz in 5 Ranges - Z 10 to 100K FS in 9 Ranges
676A RF 1969 418 1969 07 Two-Channel Tracking Phase & Amplitude Detector - Operates with 675A Sweeper from 10kHz to 32MHz
803A VHF 1950 46 1950 04 VHF Bridge 50 to 500MHz - Measure Z 2 to 2KOhms & Phase +/- 90°
8405A UHF 1966 6 1966 05 Vector Voltmeter 1 to 1000MHz - 100µV to 1V F.S. & +/- 180° Phase
8410B MW 1976 428 1969 01(A) Analog Network Analyzer - Work with 8411A Sampler - 110MHz to 18GHz
8410C MW 1983 450 1969 01(A) Automatic Freq. Locking Multi Octave Network - Work with 8411A Sampler -,11 to 18GHz
8411A MW 1967 244 1967 02 Harmonic Frequency Converter ,110 to 12,4GHz for 8410X Mainframe - 2 x 50 Ohms Inputs
8412A NA 1971 72 - Plug-In CRT Phase Magnitude Display for 8410X Mainframe
8412B NA 1983 451 1969 01(A) Plug-In CRT Phase Magnitude Display for 8410X Mainframe - Programmable Phase Offset
8414A NA 1967 244 1967 02 Plug-In CRT Polar Display for 8410X Mainframe
8418A NA 1972 368 - Auxiliary Power Supply for 8412, 8413 or 8414 Display in 8410X Network System
8503A UHF 1976 418 1976 06 S Parms Test Set 500kHz to 1,3GHz - 50 Ohms 40 dB Directivity
85044A MW 1987 625 - Transmission/Reflection Test Set 300kHz to 3GHz - 50 Ohms for 8753, 8754 or 4195
8505A UHF 1976 416 1976 07 RF Network Analyzer ,5 to 1300MHz - 100 dB Dynamic - LED Digital Readout - Work with 8502/3 Test Sets
85081A UHF 1989 242 - High Z Probe Input for 8508A Vector Voltmeter - 100kHz to 1GHz
85082A MW 1989 242 - 50 Ohms Probe Input for 8508A Vector Voltmeter - 300kHz to 2GHz
8508A UHF 1989 242 - Vector Voltmeter 1 to 1000 or 2000MHz (depend of probe) - 10ÁV to +16dBm F.S. & +/- 180░ Phase
8510C MW 1991 248 1987 02 Microwave Network Analyzer 45MHz to 110GHz - 80dB Dynamic Range - Works with 851X Test Sets
8515A MW 1985 564 1987 02 S Parms Test Set 45MHz to 26,5GHz - 50 Ohms APC3,5 - Part of 8510X Network Analyzer Systems
8740A MW 1967 244 1967 02 Transmission Test Unit for 8410X Network System DC to 12,4GHz - 50 Ohms APC7
8743A MW 1989 475 1969 01 Reflection/Transmission Test Unit for 8410X Network System 2 to 12,4GHz - 50 Ohms APC7
8745A MW 1989 476 1969 01 S Parameter Test Unit for 8410X Network System 100MHz to 2GHz - 50 Ohms APC7
8753A MW 1987 623 - Digital Network Analyzer 300kHz to 3GHz - 100dB Dynamic
8754A UHF 1979 458 1979 10 Analog Network Analyzer 4MHz to 1,3GHz - 80 dB Dynamic
8755A MW 1973 401 1972 11 Frequency Response Test Set - Gain/Loss/Return Loss ,1 to 18GHz with 1166X Detect,
8757A MW 1985 535 1986 02 Digital Scalar Network Analyzer - Work with 8350B Sweeper & 1166XX Detectors
Test Fixtures
MODEL RANGE INTRO Pg HP-JRNAL COMMENTS
11600A MW 1969 476 1969 01 Transistor Fixture for TO18/TO72 packages - S Parms Caracterisation DC to 2GHz
11602A MW 1969 476 1969 01 Transistor Fixture for TO5/TO12 packages - S Parms Caracterisation DC to 2GHz
11608A MW 1971 73 - Transistor Fixture for Micro-stripline Packages - S Parms Caracterization DC to 12,4GHz
16008A DC 1969 223 - Resistivity Cell for 4329A High Resistance Meter - Volume & Surface Resist of Material Up to 10E18 Ohms
16015A RF

- Test Fixture with Reset Button for 4270A Capacitance Bridge
16021A RF 1978 89 - Calibration Connector for 4271A LCR Meter and 4272A Preset C Meter
16022A RF 1977 83 - General Purpose Test Fixture for 4271A LCR Meter and 4272A Preset C Meter
16023B RF 1985 209 - DC Bias Controller for 4274A - 4275A - Control Range +/- 99,9 Volts thumbwheel Switch Setting
16034E VHF 1988 277 - Chip Type & SMD Components Test Fixture for 419X & 427X LCR Meter - 4 Wire BNC
16047A RF 1982 113 - Direct Coupled Test Fixture for 4192A & 427X LCR Meter - 4 Wire BNC
16047C VHF 1981 113 - 2 Terminal Test Fixture 4192A & 427X LCR Meter - 4 Wire BNC
16048C RF 1985 209 - Kelvin Alligator Clips Test Fixture for 427X LCR Meter - 4 Wire BNC
16054A DC 1980 99 - Connection Selector for 4140X pA Meter
16055A DC 1980 99 - Test Fixture with Shielded Cover for 4140X pA Meter
16057A DC 1980? - - Switching Module for 4140X pA Meter & 427X LCR Meter
16061A RF 1978 81 - Five Terminal Test Fixture for 4261A Digital LCR Meter - Inserts for Axial or Perpendicular Leads
16062A RF 1978 81 - Five Terminal Test Fixture for 4261A Digital LCR Meter - Test Leads with Alligator Clips
16085B VHF ?

- Terminal Adapter - 4 Wire BNC to APC7
16091A UHF 1980 101 1980 01 Coaxial Fixture Set for Components Measurement with 4191A & 4195A Network
16092A UHF 1980 101 1980 01 Spring Clip Test Fixture for Components Measurement with 4191A & 4195A Network
16093A VHF 1980 101 1980 01 Binding Post Fixture for Components Measurement with 4191A & 4195A Network
16099A RF 1982 119 - Test Fixture Adapter for 4193A or 4815A Probe to APC-7 Connector (Socket for 16092A Fixt)
16192A VHF 1994 357 - Parallel Electrode SMD Components Test Fixture for 419X Network
Calibration & Verification Kits
MODEL RANGE INTRO Pg HP-JRNAL COMMENTS
11866A MW 1980 477 - APC7 Calibration Kit - 50 Ohms Load + Open + Short
85029A MW 1987 627 - APC7 Verification Kit - 50 Ohms - 20 dB + 50 dB Pads + Mismatch Attenuator
85050A MW 1985 565 - APC7 Precision Calibration Kit - 50 Ohms Load + Open + Short + Sliding + Gauge
85051A MW 1985 565 - APC7 Verification Kit - 50 Ohms Air Line + 25 Ohms Betty Line + Attens
85052A MW 1985 565 - APC3,5 Calibration Kit - 50 Ohms Load + Open + Short + Sliding + Gauges
85052C MW 1991 252 - APC3,5 Precision Calibration Kit - 50 Ohms - Full 2 Ports TRL Calibration
