Click here to go back HP 606B Inside View
Inside view of a 606B Signal Generator, RF shield removed. The unit shown was produced in 1974. The early production of HP 606A was full vacuum tube. The 606B includes a lot of transistors, mostly in the power supply and calibrator circuitry.
